S-5-E Metal Roof Clamps
The S-5-E clamp is designed specially for double-folded standing seam roof profiles having the appropriate dimensioning.
Although a bit smaller and less expensive than the S-5-U, for these profiles, the S-5-E is just as strong. The S-5-E is perfect for use with S-5!® ColorGard® snow retention systems and other heavy-duty applications.
Installation is as simple as placing the clamp on the seam and tightening the patented round-point setscrews to the specified tension. Then, affix ancillary items using the bolt provided.
Specifications:
- Comparable strength to S-5-U or S-5-V but at a lower cost
- Compatible with Butler’s MR-24® and other double-folded, standing seam metal roof
- Snow retention and other heavy-duty applications
- Two T-30 Torx round-point setscrews (Torx bit tip provided)
- One M8 bolt included
It is also available in the smaller S-5-E (Mini).
The S-5-E clamp, tailored for European double-folded standing seams, provides a secure, non-penetrative attachment for solar panels and other rooftop accessories, preserving roof integrity.
If this clamp does not match your roof profile, browse our other metal roof clamps below to find one that best matches your roof profile.
S-5! offers two main warranties: a Lifetime Product Defect Warranty, covering defects in materials and workmanship, and a System Performance Warranty for the ColorGard® Snow Retention system, which is unique in the snow guard market and has a term of 30 years or the life of the roof, whichever comes first. The Product Defect Warranty has been extended to a lifetime term based on their long history of minimal claims and their products designed to outlast the roofs they are mounted on. For more detailed information, please visit the S-5! Warranty page.
